Product Number: EX20062812

|

Model: MSW-EEM-AD02

Factory second 3 Phase Induction Motor - 5.5 kW - 2950 rpm - 230/400 V - IE3

Factory second 3 Phase Induction Motor - 5.5 kW - 2950 rpm - 230/400 V - IE3
Factory second 3 Phase Induction Motor - 5.5 kW - 2950 rpm - 230/400 V - IE3 (Frequency [Hz]: 50)
Factory second 3 Phase Induction Motor - 5.5 kW - 2950 rpm - 230/400 V - IE3 (Shaft_length: 80 mm)
Factory second 3 Phase Induction Motor - 5.5 kW - 2950 rpm - 230/400 V - IE3 (Shaft diameter: 38 mm)
Factory second 3 Phase Induction Motor - 5.5 kW - 2950 rpm - 230/400 V - IE3 (Max output power: 5.5 kW)
Factory second 3 Phase Induction Motor - 5.5 kW - 2950 rpm - 230/400 V - IE3 (Emitted noise: 79.5 dB)
Factory second 3 Phase Induction Motor - 5.5 kW - 2950 rpm - 230/400 V - IE3
Factory second 3 Phase Induction Motor - 5.5 kW - 2950 rpm - 230/400 V - IE3 (Frequency [Hz]: 50)
Factory second 3 Phase Induction Motor - 5.5 kW - 2950 rpm - 230/400 V - IE3 (Shaft_length: 80 mm)
Factory second 3 Phase Induction Motor - 5.5 kW - 2950 rpm - 230/400 V - IE3 (Shaft diameter: 38 mm)
Factory second 3 Phase Induction Motor - 5.5 kW - 2950 rpm - 230/400 V - IE3 (Max output power: 5.5 kW)
Factory second 3 Phase Induction Motor - 5.5 kW - 2950 rpm - 230/400 V - IE3 (Emitted noise: 79.5 dB)
1/6
Factory second 3 Phase Induction Motor - 5.5 kW - 2950 rpm - 230/400 V - IE3
Factory second 3 Phase Induction Motor - 5.5 kW - 2950 rpm - 230/400 V - IE3 (Frequency [Hz]: 50)
Factory second 3 Phase Induction Motor - 5.5 kW - 2950 rpm - 230/400 V - IE3 (Shaft_length: 80 mm)
Factory second 3 Phase Induction Motor - 5.5 kW - 2950 rpm - 230/400 V - IE3 (Shaft diameter: 38 mm)
Factory second 3 Phase Induction Motor - 5.5 kW - 2950 rpm - 230/400 V - IE3 (Max output power: 5.5 kW)
Factory second 3 Phase Induction Motor - 5.5 kW - 2950 rpm - 230/400 V - IE3 (Emitted noise: 79.5 dB)
On Sale
Seconds
Our factory seconds are generally refurbished customer returns or former display items. The products may have cosmetic defects but are technically flawless. As usual, we provide the normal right of return and warranty.
£269.00 £329.00
Limited time offer £224.17 net (20% VAT excluded)
Last pieces! Items left: 1
FREE DELIVERY approx. Tuesday, 22 July
Lowest price guaranteed
MSW logo
Key features
  • High efficiency – 3-phase asynchronous motor with 5.5 kW output and IE3 efficiency class for powerful yet energy-saving operation at 2950 rpm
  • Multi-voltage support – induction motor runs at 240 or 400 V and includes a standard motor shaft (38 mm diameter, 80 mm length)
  • Compact & stable – the lightweight aluminium construction and large feet keep the three-phase motor stable and quiet in use
  • Safe to use – IP54-rated induction motor features a cooling fan for overload protection, plus a junction box and cable gland for easy installation
  • Premium build – IE3 motor with top-quality bearings and copper winding for enhanced heat dissipation and efficiency
Delivery details
Spare parts
Returns and Premium Guarantee

Technical details

Frequency [Hz]
50
Shaft_length
80 mm
Shaft diameter
38 mm
Max output power
5.5 kW
Emitted noise
79.5 dB
Current [A]
13
Material
Aluminium alloy
Powder-coated steel
Frame size [mm]
132
Torque [Nm]
18.1
Rotational speed [rpm]
2950
Colour
Grey
Efficiency [%]
89.2
Voltage [V]
230/400
Engine power [hp]
7.5
Power factor
0.78
Insulation class
F
IP protection class
IP54
EEI (Energy efficiency ratio)
IE3
Dimensions (LxWxH)
48 x 25.5 x 32 cm
Weight
41.85 kg
Shipping dimensions (LxWxH)
51 x 29 x 36 cm
Shipping weight
45.6 kg

Delivery package

  • 3 Phase Motor MSW-EEM-AD02

Product Description

Optimised for power and efficiency: the 5.5 kW MSW asynchronous motor

With a rated power of 5.5 kW and 2950 rpm, the three-phase induction motor from MSW provides an ideal solution for demanding industrial applications. Equipped with an operating voltage range of 230/400 V, this three-phase motor is designed for non-stop operation. IE3 efficiency keeps energy use low while delivering reliable, high performance. A lightweight aluminium frame and powder-coated steel construction give this motor exceptional durability under mechanical stress. The 38 mm x 80 mm shaft enables precise power transfer and a torque of 18.1 Nm.

The reliable, low-maintenance induction motor

Moreover, the IP54-rated IE3 motor protects against dust and splashes, ideal for challenging environments. The built-in cooling fan prevents overheating, allowing continuous operation without loss of performance. Its high-quality bearings cut down on friction and heat, boosting motor longevity and reducing maintenance needs. The copper winding improves thermal conductivity, ensuring consistent efficiency. A cable gland and a connection box enable secure installation and stable operation for long-term, reliable use across a wide range of applications.
