Technical details
Product Description
Ratings & reviews
Technical details
Height [mm]
1650-2350
Effective height [mm]
1300-2000
Fork cross section [mm]
100 x 40
+
350-900
Length of fork
1000 mm
Automatic balanced weight
300 kg
Load capacity - capacity max.
1500 kg
Dimensions (LxWxH)
110 x 93 x 244.5 cm
Weight
156 kg
Shipping dimensions (LxWxH)
172 x 130 x 23 cm
Shipping weight
165 kg
Delivery package
Pallet fork SBS-CF-1500
Instruction manual
Product Description
Move loads safely with the pallet fork
Safely move heavy loads weighing up to 1500 kg with the pallet fork SBS-CF-1500 from Steinberg Systems. As an attachment for lifting equipment, it can be used wherever Euro pallets need to be picked up and moved professionally. It can also be used in construction and for industrial and agricultural goods.
The pallet fork impresses with easy installation on the lifting equipment
The crane fork can be quickly and easily connected to the lifting equipment. It is suited for installing on cranes with and without swivel arms as well as for cranes with an HDS grabber.
The pallet fork for Euro pallets automatically adjusts to the load weight, ensuring that the pallet is aligned exactly parallel to the ground. The automatic weight compensation of 300 kg keeps it always balanced and thus enables stable transport.
To ensure the safety of goods during transport, the height of the fork carriage is adjustable in a range of 1300-2000 mm. Euro pallets can be placed lengthwise as well as crosswise. With the help of the fork carriage and fork spring, the crane fork adapts to the load centre and thus ensures an even weight distribution on both forks. These can also be adjusted.
The entire crane fork is made of resilient steel. The material longevity can be enhanced by weather-protected storage. It should also be cleaned regularly with suitable cleaning agents.
